Free chart maker that reads your data first
Most online chart makers start from a gallery. You pick a chart type, map your columns, fix the formatting and write the title yourself. Chart Studio starts from the file: it works out what each column means, then suggests charts that fit and drafts a headline, subtitle and caption from the numbers.
It accepts CSV, TSV, Excel (.xlsx, .xls), JSON and NDJSON, or rows pasted from Excel or Google Sheets. The file is read in your browser and never uploaded, so you can use it on embargoed figures and internal reports. You don't need an account.
How to make a chart
1. Load your data
Upload a file, paste a table or open a sample dataset. A preview shows the detected type of every column (time, category, number, text), and you can change any of them. Three common export problems are fixed on load. Numbers stored as text in European format, like 1.234,5 or 12%, become numbers. Excel serial dates like 46341.04 become real dates. A fixed export time such as 00:59 repeated on every row is removed.
2. Pick the chart
The gallery of 130 chart types is sorted for your data. Each card is drawn with your own rows and shows the question the chart answers, such as "Who overtook whom?" or "Is the gap closing?". It also says why it is recommended (for example "Year: 201 yearly periods, one line per region") or what is missing, like "Needs daily dates". You can filter by family or search for words like "share" or "overtook".
3. Edit and export
The editor shows the chart at full size and has six tabs: Data, Highlights, Text, Style, Axes and numbers, and Layout. When you are done, export a PNG, SVG, standalone HTML page or iframe embed, or copy a share link.
How it reads your columns
Each column gets a role as well as a type, and the role decides how the chart is built.
- Year and date columns become the time axis. Dense series are grouped for you (221 days become 11 months), and you can change the grouping.
- Date parts such as Month (1 to 12) or Hour (0 to 23) are used as groups and never summed.
- Columns that only hold 0 and 1 are shown as a percentage share.
- Percentages and rates, recognised by "%", "rate" or "share" in the name, are averaged.
- Levels like price, average, index, temperature or population are averaged too.
- Quantities like revenue, sales, cases or amounts are summed, with € or $ added when the column name suggests a currency.
- Country columns, including Italian country names, enable the world map. Latitude and longitude columns enable the point map.
- Ordered answers like "Agree / Neutral / Disagree" enable the Likert chart, and two groups such as men and women enable the population pyramid.
- Identifier columns, with a different value on every row or names like ID or code, are left out of charts.
So a pie chart is offered only when the measure adds up to a whole. A calendar needs daily dates, a spiral needs at least two years of monthly data, and a world map needs eight or more countries; with fewer, you get a bar chart instead. Charts with more than ten lines keep the nine largest and group the rest as "Other". If you pick a chart that doesn't suit the data, the editor warns that it could mislead readers and links to charts that fit.
The 130 chart types
Every chart in the catalogue lists the question it answers, when to use it, when to avoid it, and the kind of story it tells: change, ranking, share, distribution, relationship, flow or a single value.
Change over time
Line, area, stacked area, streamgraph, step line, indexed lines (base 100), cumulative total, change from the previous period, rolling average, gap between two lines, uncertainty band, seasonal lines year over year, year by month heatmap, record periods, trend projection, above or below average, warming stripes, spiral, calendar, slope chart, Gantt, event timeline and sparkline table.
Comparison and ranking
Column, bar, lollipop, diverging bars, bump chart, grouped columns, butterfly, bullet, dot plot, arrow plot, dumbbell, bars against the average, deviation from the average, pictograms, proportional squares and circles, progress bars, Pareto 80/20, colour-coded table, circular barplot and bars with change.
Parts of a whole
Pie, donut, donut with total, half donut, Nightingale rose, waffle, 100 dots, parliament hemicycle, single 100% bar, 100% bars, marimekko, pie grid and funnel.
Distributions
Histogram, histogram with density, box plot, box plot with points, violin, raincloud, beeswarm, strip plot, ridgeline, ECDF, deciles, population pyramid, Likert and error bars.
Relationships
Scatter, bubble, scatter with trend line, quadrants, scatter by group, log scale scatter, scatter matrix, correlation matrix, 2D density, connected scatter, and two measures on two axes.
Flows, networks and hierarchies
Sankey (also vertical), alluvial, chord, network, circular network, force-directed network, arc diagram, flow matrix, treemap, sunburst, icicle, tree, radial tree and circle packing.
Single values and maps
Big number with trend, KPI grid, gauge, speedometer, progress ring, world map and point map.
Headlines written from the numbers
For each chart, Chart Studio drafts a title, subtitle and caption based on the story the chart tells and on what the columns mean. On a long, uneven series it compares several years at the start with several years at the end instead of two single points. It leaves partial months out of comparisons and says so in the caption. Shares are described in percentage points ("from 20% to 32.5%"). Prices, rates and 0/1 columns are never summed, and acronyms stay in capitals, so GDP doesn't become gdp.
Some example headlines: "Revenue rose 142% from 2025-03 to 2025-11", "No majority: Right is the largest with 160 of 400", "Germany climbed from #4 to #1". With two measures you get something like "The higher the GDP, the lower the …", with the correlation coefficient and a note that correlation doesn't imply causation. You can edit every text, and "Rewrite from the data" regenerates it after you change columns. The generated headlines are in English for now.
Highlights and annotations
The Highlights tab lists what Chart Studio finds in the data, each item written as a sentence. It reports the peak and the lowest point, the sharpest rise and fall between two periods, the overall trend, the average and how many values are above it, a new record in the latest period, the longest run of increases or decreases, and outliers. For categories, it says how much of the total the first one accounts for.
You can add any item to the chart as a note, shaded range, average line or dashed trend line, or use it as the caption or the headline. Reference lines, ranges and notes can also be added by hand, or by clicking a point or bar on the chart.
Styles, number formats and layouts
There are 20 ready styles, including newspaper, financial, magazine, swiss, terminal, pastel and high contrast. You can edit the palette one colour at a time, or highlight one category and turn the rest grey. Numbers can follow Italian (1.234,5), English (1,234.5), French or Swiss conventions, with abbreviations like 12K and 3.4M, prefixes, suffixes, decimals and custom axis ranges.
Layouts cover a 640px article, a 960px wide page, a 1080×1080 social post and a 1080×1920 vertical story. Ctrl+Z and Ctrl+Shift+Z undo and redo, and your work is saved in the browser, so you can close the page and come back to it later.
Export formats
- PNG: a high-resolution image with title, chart, caption, notes and source, for articles, social posts and newsletters.
- SVG: a vector file that stays sharp at any size, for Illustrator, Figma or print.
- HTML: a standalone page with real text that search engines and screen readers can read, and an SVG chart that resizes with the page.
- Embed: an iframe code copied to your clipboard, to paste into WordPress or another CMS.
- Link: a URL that reopens the chart with its settings, and with the data too when the dataset is small.
- Config: a JSON file with every setting, for archiving and reuse.
The HTML export and the embed contain no scripts, so they work in any CMS, and both include a text description of the chart for screen readers.
Chart Studio compared with Datawrapper, Flourish, RAWGraphs and Infogram
Datawrapper and Flourish are very good at drawing and publishing charts, and Flourish is ahead on interactive, scrolling stories. RAWGraphs is still the reference for unusual vector charts, and Infogram for infographics. With all four, you choose the chart and write the text yourself.
Chart Studio recommends the chart from what your columns mean, explains why, and drafts the headline and highlights from the numbers. Like RAWGraphs, it reads your file in the browser. The full comparisons are on the Datawrapper, Flourish, RAWGraphs and Infogram pages.
Free plan and Pro
All 130 chart types, the column roles, the generated headlines and the highlights are free, with or without an account. The free plan includes one export a day (PNG, SVG, HTML or embed) with a small "Made with Datastripes" credit, and 45 of the 130 charts carry a watermark. With a free account you can also start a chart from a project already saved in Datastripes.
Pro costs €79 once, with no subscription. It gives unlimited exports with no credit and no watermark, and it covers the whole Datastripes app.
What it doesn't do yet
Published HTML and embeds are static, with no tooltips, zoom or animation. There are world and point maps, but no maps of regions, provinces or municipalities. Scrollytelling, bar chart races, shared folders, roles and approval workflows aren't available, and a chart doesn't update when its source file changes. For interactive stories and dashboards from the same data, use the full Datastripes app.
Frequently asked questions
Is this chart maker free?
Yes. Every chart type and feature works without an account. The free plan allows one export a day with a small credit, and Pro removes both limits for €79 once.
Is my data uploaded anywhere?
No. Files are read in your browser. A share link contains the data only if the dataset is small (about 60 KB compressed) and only when you create the link.
Can I make a chart from Excel or Google Sheets?
Yes. Upload an .xlsx or .xls file, or copy cells from Excel or Google Sheets and paste them into the paste box.
Which chart should I use for my data?
Load your file and start from the top of the gallery. Charts are ranked for your columns, and each card says why it fits or what is missing.
Can I embed the chart on my website?
Yes. Copy the iframe embed code or export a standalone HTML page. Neither contains scripts, so both work in WordPress and most other CMSs.
